Unlocking Large Scale Wi-Fi Coverage

The Apogee™ 360 Wi-Fi antenna Platform is a breakthrough in wireless technology, designed to deliver expansive, high-performance Wi-Fi coverage with minimal infrastructure. Built for versatility and scalability, Apogee™ 360 gives businesses the ability to provide consistent, reliable connectivity across even the most challenging environments.

download data sheet
apogee360heroangle
railyard
Omnidirectional Optimization
Apogee™ 360 is the world’s first antenna platform that overcomes strict FCC RF power limits to produce Wi-Fi coverage areas of unprecedented size and performance. Developed through years of rigorous lab and field trials, Apogee’s revolutionary approach to RF propagation unlocks the true potential of license-free networks and makes dependable, ubiquitous WiFi coverage truly scalable. Apogee™ has been deployed with success in a variety of environments, including big box retail, distribution centers, air cargo hubs, intermodal freight depots, farmland, urban centers, and more.

Asymmetric Gain™

Apogee's Asymmetric Gain provides wireless devices with up to 24dbi of additional receive gain while keeping transmit gain FCC­ compliant. This enables very low power devices like smart phones, tablets and even loT sensors to reliably connect over large distances.

Full Beamwidth Gain™

Unlike traditional antennas each Apogee panel generates 9dbi of passive peak transmit gain over its entire 90° beamwidth in both the 5GHz and 2.4GHz bands. Operating together, Apogee's 4 panels generate a full 360° of 9dbi passive gain.

Steep, Powered Filters

Apogee features steep, powered filtering for both the 5GHz and 2.4GHz bands. Combined with Apogee's Asymmetric gain, the resulting receive signal is both powerful and quiet.

inside
apogee360

more than 10x coverage

Just one of Apogee’s four 90° panel antennas can deliver high-quality Wi-Fi coverage over 5 acres, depending on the environment and application. Together, these panels extend reliable coverage across up to 20 acres with up to 90% less infrastructure leads to lower CAPEX and OPEX, significantly boosting ROI and delivering the most cost-effective large-scale Wi-Fi 5 and Wi-Fi 6 deployments available.

4-Panel Phased Array Antenna
  • 90° beam width
  • Supports 2400 MHZ to 2485 MHZ
  • Supports 5250 MHZ to 5900 MHZ (Wi-Fi 5 & Wi-Fi 6)
  • Asymmetric Gain (9dbi Tx gain & 24 dbi Rx gain)
  • Each 90-degree panel can be independently configured as 5GHz, 2.4GHz or dual band
  • Vertical, Horizontal and Aura Wireless’ proprietary hybrid polarity. Like band selection, polarity can be assigned on a port by port basis
Ports & Connected Devices
  • 4 SMA male RF ports. Each port can be configured as single band or dual band
  • Each port can be configured independently as vertical, horizontal or hybrid polarity
  • Supports FCC-compliant AP’s equipped with external RF ports.
  • One RJ45 PoE+ PoE Ethernet port
MIMO & Apogee™
  • 4×4 MIMO (≈90° coverage): Assign four external radio chains to a single Apogee panel (≈90° sector).
  • 2×2 MIMO (≈90° coverage): Assign both external ports of a 2×2 radio to a single Apogee panel (≈90° sector).
  • 2×2 MIMO across ≈180°: Use two 2×2 radios or one 4×4 radio split as 2×2 + 2×2, assigning two chains to each of two adjacent panels (≈180° total).

Apogee 360 — Product Specifications

Specification Detail
Operating Frequencies 2.4 GHz, 5.2–5.9 GHz (Wi-Fi 5, Wi-Fi 6)
Transmit Gain 9 dBi
Receive Gain 24–26 dBi
RF Power Input Up to 2 watts
External RF Ports 4 SMA male external RF ports
Array Sectorization Up to [4] 90° panels
Polarization Vertical, horizontal, hybrid
Hybrid Polarization Designed for severe multi-path environments
Control Interface 1× RJ45 Ethernet/LAN 10/100 Mbps
Auxiliary Port 1× RJ45 serial
Status LEDs 2× (red/green)
Encryption AES 256-bit
PoE Injection Voltage 7–55 volts
Supply Voltage 48 V DC nominal (+/- 7 V DC)
Height, OD, Weight 22" height, 12" OD, 22 lbs
Environmental -40°C to +60°C, IP65 certification
Configuration/Mgmt Apogee Manager™ (Cloud)
DC Power PoE 802.3af/at compatible (Endspan & Midspan/Mode B Class 2)
asymetric gain

Apogee™ generates a Wi-Fi & CRBS receive gain of 24dbi while keeping transmit gain at an FCC-compliant 9dbi. This Asymmetrical Gain™ enables all your devices to connect and stay connected to your operation’s wireless network reliably over large distances.

patented benefits

Unlock Large Scale Wireless Coverage

01
Asymmetric Gain™

Apogee's Asymmetric Gain provides wireless devices with up to 24dbi of additional receive gain while keeping transmit gain FCC­ compliant. This enables very low power devices like smart phones, tablets and even loT sensors to reliably connect over large distances.

02
Steep, Powered Filters

Apogee features steep, powered filtering for both the 5GHz and 2.4GHz bands. Combined with Apogee's Asymmetric gain, the resulting receive signal is both powerful and quiet.

03
Full Beamwidth Gain™

Unlike traditional antennas each Apogee panel generates 9dbi of passive peak transmit gain over its entire 90° beamwidth in both the 5GHz and 2.4GHz bands.

04
Multipath performance

Engineered with hybrid-polarity design, the Apogee 360 and 180MP capitalizes on RF signals that deflect and reflect. When one polarity experiences interference, the other maximizes performance, effectively mitigating multi-path fading. This ensures uninterrupted, consistent connectivity across expansive spaces.

insights

Real deployments. Real solutions. Built to deliver the science of scale.

become a certifed partner

Our patented Apogee™ antenna technology reduces access point counts by up to 83% — cutting costs, simplifying installs, and delivering performance your clients can see.
